EnGenius ESA7500 Surge Arrester

Surge Arrester
Superior lightning and surge protection

Compatible with Power-over-Ethernet (PoE)

Supports normal and reverse polarity PoE

PRODUCT DESCRIPTION
The Lightning Protector provides superior lightning and surge protection for both
indoor and outdoor 10/100 Base-T networks. The unit meets or exceeds CAT5e
performance for the two data pairs. In addition, the unit is compatible with 802.3af
Power-over-Ethernet (PoE) devices. Integral to the design is protection for the
two Ethernet data pairs and the PoE DC power feed. This unit supports normal
and reverse polarity PoE
PRODUCT HIGHLIGHT
 10/100 Base-T CAT5 protection.
 Convenient and integral mounting.
 802.3af Power-over-Ethernet (PoE) Compatible
 DC spark-over voltage ：75V +-25%
 Impulse spark-over voltage ：at 100V/us <=500V at 1kV/us <=600V
 RoHS Compliant
 PCBA components
PRODUCT ID & COSMETIC
 Two arc type mechanical design for mounting
 Dimension: 130 x 78 x 50mm
OPERATION ENVIRONMENT
 Operation temperature: -20°C~ +60°C
 Storage temperature: -40°C~ +85°C
 Humidity: 5% ~ 95% typical
Reliability
20,000 hours
RJ-45
Surge absorber ES75XPA*10
PCB 2-layer FR-4 50x40x1.6mm
EARTH PARTS INCLUDE SCREW
